AMDT 13.2 kV 60 Hz Single-Phase Pole-Mounted Distribution Transformer

AMDT 13.2 kV 60 Hz Single-Phase Pole-Mounted Distribution Transformer

Oil-Immersed

AMDT 13.2 kV 60 Hz Single-Phase Pole-Mounted Distribution Transformer

AMDT 13.2 kV 60 Hz Single-Phase Pole-Mounted Distribution Transformer

Best fit

For 60 Hz single-phase overhead distribution networks serving rural communities, farms, small commercial loads and remote sites.

What it does

The AMDT pole-mounted transformer steps a 13.2 kV-class primary supply down to 120/240 V. Its cylindrical sealed oil tank and PCB-free insulating-oil requirement support outdoor pole-mounted service. The 50 kVA reference unit can be coordinated with project protection, mounting and accessory requirements.

Why buyers choose it
  • Compact cylindrical construction for pole-mounted installation.
  • Single-phase 60 Hz configuration for overseas distribution networks.
  • 120/240 V secondary arrangement for residential and light-commercial loads.
  • Sealed oil-immersed construction for outdoor service.
  • Capacity, primary connection, corrosion protection and accessories can be configured after engineering review.
Before quotation

Please confirm primary voltage and connection, capacity, frequency, secondary voltage, insulation/BIL, applicable standard, mounting, protection, accessories, ambient conditions, quantity and destination country.

CategoryOil-Immersed
Voltage7,620 V or 13,200 V
Capacity15 / 25 / 37.5 / 50 / 75 / 100 / 167 kVA

Application Scenarios

Power DistributionFor factories, parks, utilities, and project power rooms.
Industrial LoadsSupports stable voltage conversion for continuous production loads.
Project DeliverySuitable for packaged delivery with switchgear and site accessories.

Selection & Delivery Notes

  • Voltage: 7,620 V or 13,200 V | Capacity: 15 / 25 / 37.5 / 50 / 75 / 100 / 167 kVA
  • Confirm the required voltage level, rated capacity, frequency, and installation environment.
  • Share the destination country, quantity, project schedule, and whether drawings or technical documents are required.
  • Use the inquiry form on this page so the sales and engineering team can reply with a matched configuration.

Product Parameter

Product ModelAMDT
Transformer TypeSingle-phase pole-mounted oil-immersed distribution transformer
Rated Capacity Options15 / 25 / 37.5 / 50 / 75 / 100 / 167 kVA
Rated Frequency60 Hz
Primary Voltage Options7,620 V or 13,200 V
Secondary Voltage120/240 V
InstallationOutdoor pole-mounted
Tank TypeCylindrical sealed tank
Insulating MediumPCB-free insulating oil

Project & Export Support

Custom SpecificationsVoltage, capacity, cabinet layout, and project configuration can be discussed with Longxiang engineers.
Catalogs Upon RequestProduct catalogs and technical documents are available through sales instead of public download at this stage.
Selection GuidanceShare load demand, installation environment, grid requirements, and application scenario for technical matching.
After-sales SupportEmail support, remote technical guidance, and spare parts consultation can be arranged for project needs.

Product FAQ

Can Longxiang support custom voltage or capacity?

Yes. Custom specifications are available on request after engineers review the project requirements.

Can I request OEM or project-matched equipment?

Project matching and OEM-style requirements can be discussed with the sales and engineering team.

Can these products be supplied for Middle East, Africa, or Southeast Asia projects?

Longxiang can discuss overseas project requirements and provide technical selection support. Final export documents and terms should be confirmed with sales.

How do I get a quotation?

Send the product type, country, quantity or project scale, and required voltage or capacity. Engineers will review the requirement before quotation.
